Product Attribute Attribute Value Select Attribute
Manufacturer: Amphenol
Product Category: Automotive Connectors
RoHS:
Product: Connectors
Number of Positions: 4 Position
Pitch: -
Mounting Style: Cable Mount / Free Hanging
Termination Style: -
Wire Gauge Min: 22 AWG
Wire Gauge Max: 16 AWG
Color: Gray
Series: ATM
Brand: Amphenol SINE Systems
Contact Gender: Socket (Female)
Contact Type: Socket
Current Rating: 7.5 A
Housing Gender: Plug (Male)
Housing Material: Thermoplastic (TP)
Ingress Protection: IP67
Insulation: Insulated
Insulation Resistance: 1 GOhms
Mating Gender: Receptacle
Mating Part Number: ATM04-4P
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
Mounting Angle: Straight
Number of Rows: 2 Row
Product Type: Automotive Connectors
500
Subcategory: Automotive Connectors
Type: 4-Way
Wire Gauge Range: 22 AWG to 16 AWG
Unit Weight: 0.184845 oz
