• Clearance: > 4.0 mm
• Color: Grey
• Contact Plating: Silver
• Contact Resistance: < 5mΩ
• Contacts: 10+PE
• Creepage: > 6.3mm
• Insert Material: PC
• Insertion/Withdrawal Force: 40-50 N
• Insulation Resistance: > 10(10) Ω
• Knurled Screw/Nut: CuZn (brass)
• Lifetime: >500 mating cycles
• Operating Temperature: -40°C to +125°C
• Protection: IP00 unmated, IP20 mated
• Rated Current: 16A
• Rated Impulse Voltage: 6000V
• Rated Voltage: max 500V (600V UL/CSA)
• Size: E10
• Termination: Screw
• Type: Female
• Weight: 39g
• Wire Gauge: 0.14- 2.5mm²
• Voltage Rating UL/CSA: 600
• Rated Voltage IEC 60664-1: 500V
