• No. of positions:12
• Amperage:7.5
• IP Rating:IP69K
• Volts:250
• Contact Size:20
• Contact type (Pin/Socket):Pin
• Plating:Tin
• Color:Black
• Operating Temperature:-55°C TO +125°C
• Housing Material:Thermoplastic
• Dielectric Value:LESS THAN 2 MILLIAMPS CURRENT LEAKAGE @ 1500 VOLTS AC
• Insulation Resistance:1000 MEGOHMS MIN @ 25°C
• Mating Cycle Durability:> 100
• Mating Part:ATM06-12SD-*
