• No of Positions:6
• Contact type (Pin/Socket):Socket
• Operating Temperature:-55°C to +125°C
• Color:Black
• IP Rating:IP67
• RoHS Compliant:Yes
• Mating Cycle Durability:>100
• Housing Material:Thermoplastic
• Seal Material:Silicone Rubber
• Mating Part:ATM04-6P* Receptacle
• No. of Positions:6
• AWG:16-22 AWG
• Amperage:7.5
• Seal Diameter:1.35mm (.053 in) - 3.05mm (,120 in)
• Dielectric Value:1500V minimum
• Insulation Resistance:1000 megohms at 25°C
