• No. of positions:8-Way B Position Key
• Contact Size:20
• Contact type (Pin/Socket):Pin
• AWG:16-22
• AMP:7.5A
• Color:Black
• Seal Diameter:1.35mm (.053") - 3.05mm (.120")
• IP Rating:IP67
• Operating Temperature:-55°C to +125°C
• Dielectric Value:Less than 2 milliamps current leakage@ 1500V AC
• Insulation Resistance:1000 megohms at 25°C
• Mating Cycle Durability:>100
• Housing Material:Thermoplastic
• Seal Material:Silicone Rubber
• Mating Part:ATM06-08SX* Plug
• Wedge Part#:AWM-8P
• Mating Part(s):ATM06-08SA* Plug
• Wedgelock Part Number :AWM-8P
• Wire Range:16-22 AWG
